เครื่องรีดตะกอน แบบ Multidisc Screw Press(Sludge Dehydrator)

คุณสมบัติสินค้า:

Multidisc Screw Press เป็นเครื่องรีดตะกอนแบบสกรูมัลติดิสก์ ใช้สำหรับการแยกน้ำออกจากตะกอนคล้ายกับเครื่องรีดตะกอนแบบ Filter press ซึ่งใช้วิธีการบีบอัดตะกอนโดยการหมุนเกลียวบีบอัด ความพิเศษของเจ้าเครื่องMultidisc Screw press นี้ก็คือมีการติดตั้ง Moving ring สลับ กับ Fixed ring ในส่วน Filter Column เพื่อกรองน้ำที่รีดออกมา ตะกอนที่ออกมาจากเครื่องจะมีความแห้งประมาณ 15 – 20% ขึ้นอยู่กับชนิดของตะกอน และยังมีระบบน้ำฉีดล้างเพื่อทำความสะอาด Filter Colum ซึ่งสามารถตั้งเวลาการทำงานได้โดยผ่านตู้ควบคุม แล้วน้ำใสที่ได้จากการบีบตะกอนจะไหลออกจากเครื่องเพื่อนำไปนำบัดใหม่ ใช้งานง่าย ประหยัดพื้นที่ ใช้น้ำน้อย ใช้พลังงานน้อย ; ทีมงานเวลกิ้นฯ มีบริการปรับเคมี Cationic Polymer หลังงานติดตั้ง, เพื่อให้ได้ตะกอนที่มีความชื้นต่ำ ประหยัดค่าใช้จ่ายในการกำจัดทิ้ง

Share

ทีมงานเวลกิ้นฯ มีประสบการณ์ในการบำบัดน้ำเสีย และ งานด้านรีดตะกอนมามากกว่า 10ปี พร้อมทีมงานผู้เชี่ยวชาญในการให้คำปรึกษา และออกแบบระบบรีดตะกอน ร่วมกับการใช้งาน Cationic Polymer เพื่อให้ตะกอนมีความแห้งมากที่สุด ส่งผลให้ค่าใช้จ่ายในการส่งกำจัดกากตะกอนลดต่ำลง

  Working Principles

The conditioned sludge flows into the filter zones from the flocculation tank and is pushed forward to the discharging end. With the gaps between the thread of the shaft is getting even narrower, the pressure on the sludge is getting higher and higher, Then the water is separated from the sludge and flows out from the gaps between the moving rings and fixed rings. The movement of the moving rings will clean the gaps between moving and fixed rings and prevent the machine from blockage. The filtered sludge cakes will be pushed forward by the shaft and finally discharged form the end.



  Technology Advantages

                                                              Configurating exclusive spiral plate for pre-concentration and better for treating low
                                                              concentration sludge.



  Replacing gravity type dehydrator to realize efficient concentration of sludge.

 Flocculation and concentration operating together makes dewatering easy.

 Optimize concentration of slurry for dewatering with solenoid control valve.



  Rings substitute filter cloth, self cleaning, no clogging, easy treatment of oily sludge

The traditional dewatering equipments are easily got blocked while the dewatering screw press allows continuous operation with no clogging due to the moving of the fixed rings and moving rings cleaning itself. Therefore, it's especially good at oily sludge with excellent performance. Moreover it doesn't need additional water for high-pressure chleaning so that no smell or secondary pollution will

  Low speed operation, low energy consumption, only 1/8 of the belt type, 1/2 of the centrifuge

  Reduce the cost of infrastructure investment, improve the results of treatment

The dewatering screw press can directly treat the sludge from the aeration tank and the sedimentation tank so that the sludge thickening tank is not needed any more. Therefore, the construction cost can be greatly reduced and well avoided the phosphorus releasing problem.

  saving the cost of sludge thickening tank and other equpments investment.

 occupy smaller area, reduce construction investment for dewatering

  Fully automatic control, easy operation and maintenance

The dewatering screw press has no easy-bllocking components like filter cloth or filtration pore inside. Its operation is safe and easy. It also can be set to operate automatically via the elec-control cabinet.

  Integral construction









ชมคลิปแสดงการทำงาน เครื่องรีดตะกอนแบบ Multidisc Screw Press

เครื่องรีดตะกอน Model 131: เครื่องรีดตะกอนขนาดเล็กสุดในตระกูล สามารถรีดตะกอนได้ 6-10Kg/hour (DS), มีชุดถัง Sludge mixing ในตัว เหมาะกับงานรีดตะกอนสำหรับโรงงานขนาดเล็ก และมีราคาย่อมเยาว์

ท่านสามารถชมคลิปการทำงานของรุ่น 131  คลิปแสดงการทำงานของเครื่องมัลติดิสก์สกรูเพรสรุ่น 131

งานบำรุงรักษาเครื่อง Multidisc Screw Press (มีเศษท่อ PVC หลุดเข้าไปในเครื่อง และทำให้Ring คด เครื่องหยุดทำงาน ทีมงานเวลกิ้นฯ เข้าไปถอดRing และเปลี่ยน Ring )

ผลงานการติดตั้งเครื่องรีดตะกอน Multidisc Screwpress รุ่น 402
